Nardi Part Number: AT001-100-00-1000
Genuine Nardi 1000 Hour Service Kit for Atlantic Compressors. This item suits all Atlantic High Pressure Compressors.
KIT CONTENTS:
AT012-001 Shaft Oil Seal (Qty 1)
AT029-001 Cover Oil Seal (Qty 1)
AT036-005 Piston Ring Set 3rd Stage (Qty 1)
AT041-001 Piston Ring Set 1st Stage (Qty 1)
AT045-001 Piston Ring Set 2nd Stage (Qty 1)
OR126-001 Cover O-Ring (Qty 1)
AT059-060-080 Cylinder Gasket 1st Stage (Qty 1)
AT066-001 Top Gasket 1st Stage (Qty 1)
AT070-005 Suction Filter Cartridge (Qty 1)
AT079-001 Disc Valve 3rd Stage (Qty 2)
AT083-010 Suction Valve 2nd Stage (Qty 1)
AT083-020 Pressure Valve 2nd Stage (Qty 1)
AT085-001 Valve Cover 2nd Stage (Qty 1)
AT098-001 Valve Spring 4th Stage (Qty 2)
AT108-001 Bottom Valve Body 3rd Stage (Qty 1)
EX035-101 Valve Plate 1st Stage (Qty 1)
OR012-005 O-Ring 4th Stage (Qty 1)
OR020-006 O-Ring 4th Stage (Qty 1)
OR020-005 O-Ring 4th Stage (Qty 4)
OR022-005 O-Ring 2nd Stage (Qty 2)
OR025-005 O-Ring 4th Stage (Qty 2)
OR043-005 O-Ring 2nd Stage (Qty 1)
OR044-005 O-Ring (Qty 1)
OR063-005 O-Ring (Qty 1)
VB004-015 Valve Cover Screw (Qty 6)
VR022-005 Washer 3rd Stage (Qty 1)
AT141-001 Discharge Rilsan Nut (Qty 1)
AT142-001 Discharge Screw (Qty 1)
